DINE TRACK PROJECTOR
T-A-LEDDNG-SN4-WH
T-A-LEDDNG-SN4-BK
T-A-LEDDNG-SN2-WH
T-A-LEDDNG-SN2-BK
T-A-LEDDNG-SN1-WH
T-A-LEDDNG-SN1-BK

Liteline

DINE TRACK PROJECTOR

Price on demand

The DINE LED was specifically designed for restaurants and dining applications, allowing for ideal control of visual comfort. Low-glare lighting and flexibility to make on-site adjustments allows for perfect horizontal or vertical illumination for both high and low ceilings.
  • Body
    Constructed of aluminum which provides superior strength and rigidity, the body features an aesthetically pleasing smooth cylindrical shape with dual finish color.
  • LED Characteristics
    High powered 16W LED chip maintains uniform intensity with a typical luminous flux up to 900 lumens, with a typical CRI of 90+. Available in 3000 K color temperature.
  • Adjustability
    Lamp housing is controlled with an adjustable link that provides 90° tilt and 330° rotation (for T and MP mounting options). Lamp holder bracket is height adjustable up to 2″.
  • Beam Spread
    Beam spread dependent on attached standard Solite lens, honeycomb louver, snoot and the adjustable light source height (40° with 1″ snoot, 35° with 2″ snoot, 25° with 4″ snoot).
  • Dimming
    Color temperature dimmable from 3000 K to 2000 K when used with industry standard forward-phase/ reverse-phase controls (contact factory for compatible dimmers).
  • Mounting Options
    Multiple mounting options for various applications. Available mounting options include direct mounting onto a 4″ octagonal junction box for surface flushmount, surface pendant and monopoint applications, provided with one 7/8″ knockout with true pryout and ground wire for recessed pendant and recessed mount applications and 1- or 2-circuit track connectors for track applications (compatible with A-Line, 2- and 3-circuit Powergear, H-style, L-style and Liteline tracks). Includes two pressure spring loaded clips to attach to any ceiling material for RP and RF mounting options.
  • Compatibility
    Available track connectors for compatibility with A-Line, Global ®, Halo ®, Liteline ® and Lightolier ® track systems.
  • Warranty
    5-Year warranty.

Spec Sheet

Choose options

*Please note: Colour swatches are for reference only and may not exactly match the final product

Shipping delay : On request
